Key Features

• Premium low-frequency pneumatic suspension
• 100mm vertical suspension travel
• Adjustable shock absorber
• Electronic operator weight adjustment
• 80mm pneumatic height adjustment
• 210mm fore/aft adjustment
• Fore/aft isolator to reduce longitudinal vibration
• Active climate system
• Pneumatic lumbar support
• Operator presence switch
• Adjustable armrests
• Headrest
• Adjustable backrest angle
• Safety belt
• Seat heating
• Document holder / storage facility
• Adjustable seat cushion depth
• Adjustable seat cushion angle
• Available with 550mm or 490mm wide seat cushion
• Ergonomic design for long working periods

Low-Frequency Air Suspension

One of the main advantages of the Actimo Evolution is its low-frequency pneumatic suspension.

Large agricultural and construction machines can expose operators to continuous vibration, impacts and movement when travelling over uneven surfaces. The low-frequency suspension is designed to absorb these movements more effectively than a conventional suspension system.

Combined with the adjustable shock absorber and fore/aft isolator, the system helps reduce vibration reaching the operator and provides improved ride comfort throughout the working day.

Active Climate System

The Actimo Evolution can be equipped with an active seat climate system, helping improve operator comfort during extended periods of use.

Air circulation through the seat helps reduce heat and moisture build-up between the operator and the upholstery, making the seat particularly suitable for machinery used for long shifts.

Combined with seat heating, this provides additional comfort across changing working and weather conditions.

Typical Applications

The GRAMMER Actimo Evolution is particularly suitable for medium and large machinery where operator comfort and vibration reduction are important.

Typical applications include:

• Self-propelled agricultural sprayers
• Tractors
• Crop and harvesting machinery
• Wheel loaders
• Construction machinery
• Forestry machinery
• Material-handling equipment
• Industrial machinery
• Specialist off-road vehicles

Ideal Seat for Agricultural Sprayers

The GRAMMER Actimo Evolution is particularly well suited to self-propelled sprayers and other agricultural machines that operate for extended periods over uneven ground.

Its combination of low-frequency air suspension, fore/aft isolation, electronic weight adjustment and ergonomic seat controls helps provide a stable and comfortable driving position during long working days.

Operator Comfort & Adjustment

The Actimo Evolution offers extensive adjustment to accommodate different operators and working positions.

The 210mm fore/aft adjustment, pneumatic height adjustment, adjustable backrest, lumbar support and adjustable seat cushion allow the operator to fine-tune the seating position.

Electronic weight adjustment helps configure the pneumatic suspension for the operator, while the adjustable shock absorber allows the suspension response to be adapted to operating conditions.

GRAMMER Seats, Spare Parts & Technical Support

Seat Systems Ltd supplies GRAMMER operator seats, replacement seats, suspension units and spare parts for agricultural, construction and industrial machinery.

With over 40 years of experience in the vehicle seating industry, we can help identify the correct GRAMMER seat or replacement component for your machine.

We stock a wide range of seats, spare parts and accessories for fast order processing and dispatch.

Need Help Choosing the Correct GRAMMER Seat?

If you are replacing an existing seat, send us your machine make and model together with a photograph of the GRAMMER identification label from your current seat.

Our team can help identify the correct seat and specification for your application.
