Grammer Maximo Basic MSG85/721

Grammer Maximo Basic MSG85/721 Features

Suspension:

• Mechanical suspension with steel springs

• Suspension travel: approx. 80–90 mm

• Manual weight adjustment: approx. 50–130 kg

• Adjustment via front knob or lever

Seat Positioning:

• Fore / Aft adjustment with slide rails fitted as standard

• Adjustment range: approx. 150–210 mm

Construction & Design:

• Rugged and durable for agricultural and utility use

• Supports operators for moderate-speed tractor work

Benefits

• Reduces shocks and vibrations from uneven ground

• No air system → fewer failures, lower maintenance

• Reliable for tractors where mechanical suspension is sufficient

Applications – Grammer Maximo Basic

Category: Mechanical suspension tractor seat

Suitable For:

• Agricultural tractors

• Utility & municipal tractors

• Livestock, yard, loader, and mixed-use machines

• Machines where air suspension is not required

Typical Compatible Models

John Deere:

• 5 Series (5E, 5M, utility specs)

• 6M Series (lower-spec / mechanical seat versions)

• Municipal & utility variants

• Loader-configured tractors

Case IH / New Holland:

• Case IH Farmall series (A, C, U variants)

• New Holland T4 / T5 Series (mechanical seat specifications)

Massey Ferguson:

• MF 3000 Series

• MF 4000 Series

Deutz-Fahr:

• Agrolux

• Agroplus

CLAAS:

• Elios

• Atos

Supplier & Support

• Seats and spare parts from Grammer, Isringhausen, Pilot, SEARS, KAB

• Full technical support for vehicle seats

• Large stock for quick dispatch
