The MGV35 is a robust low-profile mechanical suspension seat, suitable for site dumpers, forklift trucks, rollers, and other small construction machinery that requires a suspension seat with a relatively low sitting height. Despite it’s low-profile, it offers a good weight range, ideal for operators of different sizes. It is built to a high standard of quality whilst still offering excellent value for money.
features
Mechanical suspension
Weight adjustment 50-150 kg
Suspension travel 80 mm
Slide rail travel 180 mm
Slide rails at 328 mm
Heavy duty PVC trim
Seat width 460 mm
Seat height 640 mm
Foldable and adjustable backrest
Seat belt
Contact switch
Options
Adjustable armrests
Headrest
Applications
Bad Boy Machines: 2300, 2600, 5200, 6000, 7200
Bobcat Part Numbers: 6675319, 6675321, 7149786 and 7167603
Bobcat Machines: Excavators; E32I, E35, E35I, E42, E50, E60. Skidsteers; 463, 751C, 753G, 763, 763G, 773, 773G, 773GT, 853, 863, 863F, 863G, 863H, 863HF, 864, 864EH, 864F, 864G, 864H, 864T, 873, 873C, 873F, 873G, 883, A300, S70, S100, S130, S150, S160, S160HF, S175, S175HF, S185, S185HF, S205, S220, S220H, S250, S250HF, S250K, S300, S330, S510, S530, S550, S570, S630, S650, T110, T140, T180, T190, T190G, T190H, T190K, T200, T200G, T200H, T250, T250G, T250H, T300, T300ACS, T300G, T300H, T300K, T320, T320H, T450, T550, T590, T630, T650, T750, T870 (verify 11.25″ wide bolt pattern)
Case Machines: 420, 430, 435, 440, 445, 445CT, 450CT, 465, SR130, SR150, SR175, SR200, SR240, SR250, SR270, SV185, SV220, SV280, SV300, TR270, TR310, TR320, TR340, TV380
Caterpillar Machines: Rollers; CB-214E, CB-22, CB-334E, CB-34. Skid Steers; 216, 216B, 216B3, 226B, 226B3, 228, 232B, 236, 236B, 236B3, 242B, 242B3, 247, 247B, 247B3, 248, 252B, 252B3, 257B, 257B3, 259B3, 267, 267B, 268B, 287.
John Deere Machines: 240, 250, 260, 270, 280, 312GR, 313, 314G, 315, 316GR, 317, 317G, 318D, 318E, 318G, 319D, 319E, 320, 320D, 320E, 323D, 323E, 324E, 325, 326D, 326E, 328, 328D, 328E, 329D, 329E, 330G, 331G, 332, 332D, 332E, 332G, 333D, 333E, 333G, CT315, CT322, CT332
New Holland Machines: C175, C185, C190, C227, C232, C238, L140, L150, L160, L170, L175, L180, L185, L190, L213, L215, L218, L220, L223, L225, L230, L554, L565, L775, L778, L779, LS140, LS150, LS160, LS170, LS180, LS180.B, LS185.B, LS190, LS190.B, LT185.B, LT190.B
Volvo Part Numbers: VOE12794493
Volvo Machines: Rollers; DD110B, DD112, DD118, DD120, DD120B, DD132, DD138, DD140, DD140B, SD25D SD25F, SD45D SD45F
